Features:
1,100% Fiberglass and resin raw materials
2,With 6-way multiport valve
3,100% ABS material for valve
4, Factory testing pressure 370-400KPA, working pressure 250KPA
5,Bobbin wound with fiberglass wires
6, Max temperature of 43°C (109°F)
7,Anti-corrosion and UV-resistant
Technical Data:
Model | Diameter | In/outlet（inch） | Design flow（m3/h） | Filtration Area | Sand Weight（kg） | Volume（m3） | Total height（mm) | Package（mm） | Weight（kg） |
NF-BS-500 | ￠500 | 1.5" | 10 | 0.2 | 62 | 0.07 | 635 | 530*530*610 | 14 |
NF-BS-600 | ￠600 | 1.5" | 15 | 0.3 | 107 | 0.12 | 700 | 630*630*670 | 21 |
NF-BS-700 | ￠700 | 1.5" | 18.5 | 0.37 | 170 | 0.19 | 835 | 710*710*760 | 26 |
NF-BS-800 | ￠800 | 2" | 25 | 0.5 | 253 | 0.28 | 970 | 830*830*930 | 36.5 |
NF-BS-900 | ￠900 | 2" | 30 | 0.64 | 361 | 0.40 | 1050 | 900*900*990 | 44.5 |
NF-BS-1000 | ￠1000 | 2" | 35 | 0.79 | 495 | 0.55 | 1100 | 1135*1135*1170 | 61.5 |
NF-BS-1200 | ￠1200 | 2" | 50 | 1.13 | 855 | 0.95 | 1290 | 1230*1230*1350 | 85 |
